NORFOLK SOUTHERN
DIESEL LOCOMOTIVE ROSTER

GE Dash 9-40C (D9-40C)/Dash 9-44C (D9-44C)
Nos. 8764-8888

125 Units Active (1 of those is currently stored)








This roster compiled and maintained by Chris R. Toth
Roster last updated on August 26, 2015.




Active Roster

NOTE: NS is currently upgrading these units from 4,000 to 4,400 horsepower.
Upgraded units are reclassified as model  Dash 9-44C (D9-44C).
(Current horsepower rating for each unit is listed on the roster below.)



Road
No.

Order
No.
Build
Date
Builder
No.
Horsepower Notes
8764 338-26925 01-1995 48224 4,000
8765 338-26925 01-1995 48225 4,000
8766 338-26925 01-1995 48226 4,000
8767 338-26925 01-1995 48227 4,000
8768 338-26925 01-1995 48228 4,000
8769 338-26925 01-1995 48229 4,000
8770 338-26925 01-1995 48230 4,000
8771 338-26925 01-1995 48231 4,000
8772 338-26925 01-1995 48232 4,000
8773 338-26925 01-1995 48233 4,000
8774 338-26925 01-1995 48234 4,000
8775 338-26925 01-1995 48235 4,000
8776 338-26925 01-1995 48236 4,000
8777 338-26925 01-1995 48237 4,000
8778 338-26925 01-1995 48238 4,000
8779 338-26925 01-1995 48239 4,000
8780 338-26925 01-1995 48240 4,000
8781 338-26925 01-1995 48241 4,000
8782 338-26925 01-1995 48242 4,000
8783 338-26925 01-1995 48243 4,000 NS LEADER/PTC Equipped.
8784 338-26925 01-1995 48244 4,000
8785 338-26925 01-1995 48245 4,000
8786 338-26925 01-1995 48246 4,000
8787 338-26925 01-1995 48247 4,000
8788 338-26925 01-1995 48248 4,000
8789 338-26925 01-1995 48249 4,000
8790 338-26925 01-1995 48250 4,000
8791 338-26925 01-1995 48251 4,000
8792 338-26925 01-1995 48252 4,000
8793 338-26925 01-1995 48253 4,000
8794 338-26925 01-1995 48254 4,000
8795 338-26925 01-1995 48255 4,000 NS LEADER/PTC Equipped.
8796 338-26925 01-1995 48256 4,000
8797 338-26925 01-1995 48257 4,000
8798 338-26925 01-1995 48258 4,000
8799 338-26925 01-1995 48259 4,000 Unit converted from DC to AC traction with new widenose and cab.  Still needs to be painted and put into service.
8800 338-26925 01-1995 48260 4,000
8801 338-26925 01-1995 48261 4,000
8802 338-26925 01-1995 48262 4,400
8803 338-26925 01-1995 48263 4,000
8804 338-26925 01-1995 48264 4,000
8805 338-26925 01-1995 48265 4,000
8806 338-26925 01-1995 48266 4,000
8807 338-26925 01-1995 48267 4,000
8808 338-26925 01-1995 48268 4,000
8809 338-26925 02-1995 48269 4,000
8810 338-26925 02-1995 48270 4,000
8811 338-26925 02-1995 48271 4,000
8812 338-26925 02-1995 48272 4,000
8813 338-26925 02-1995 48273 4,000 Unit currently stored, but still on the active roster.
8814 338-26925 02-1995 48274 4,000
8815 338-26925 02-1995 48275 4,000
8816 338-26925 02-1995 48276 4,000
8817 338-26925 02-1995 48277 4,000
8818 338-26925 02-1995 48278 4,000
8819 338-26925 02-1995 48279 4,000
8820 338-26925 02-1995 48280 4,000
8821 338-26925 02-1995 48281 4,000
8822 338-26925 02-1995 48282 4,000
8823 338-26925 02-1995 48283 4,000
8824 338-26925 02-1995 48284 4,000
8825 338-26925 02-1995 48285 4,000
8826 338-26925 02-1995 48286 4,000
8827 338-26925 02-1995 48287 4,000
8828 338-26925 02-1995 48288 4,000
8829 338-26925 02-1995 48289 4,000
8830 338-26925 02-1995 48290 4,000
8831 338-26925 02-1995 48291 4,000
8832 338-26925 02-1995 48292 4,000
8833 338-26925 02-1995 48293 4,000
8834 338-26925 02-1995 48294 4,000
8835 338-26925 02-1995 48295 4,000
8836 338-26925 02-1995 48296 4,000
8837 338-26925 02-1995 48297 4,000
8838 338-26925 02-1995 48298 4,000
8839 338-26925 02-1995 48299 4,000
8840 338-26925 02-1995 48300 4,000
8841 338-26925 02-1995 48301 4,000
8842 338-26925 02-1995 48302 4,000
8843 338-26925 02-1995 48303 4,000
8844 338-26925 02-1995 48304 4,000
8845 338-26925 02-1995 48305 4,000
8846 338-26925 02-1995 48306 4,000
8847 338-26925 02-1995 48307 4,000
8848 338-26925 02-1995 48308 4,000
8849 338-26925 02-1995 48309 4,000
8850 338-26925 02-1995 48310 4,000
8851 338-26925 02-1995 48311 4,000
8852 338-26925 02-1995 48312 4,000
8853 338-26925 02-1995 48313 4,000
8854 338-26925 02-1995 48314 4,000
8855 338-26925 03-1995 48315 4,000
8856 338-26925 03-1995 48316 4,000
8857 338-26925 03-1995 48317 4,000
8858 338-26925 03-1995 48318 4,000
8859 338-26925 03-1995 48319 4,000
8860 338-26925 03-1995 48320 4,000
8861 338-26925 03-1995 48321 4,400
8862 338-26925 03-1995 48322 4,400
8863 338-26925 03-1995 48323 4,000
8864 338-26925 03-1995 48324 4,000
8865 338-26925 03-1995 48325 4,000
8866 338-26925 03-1995 48326 4,000
8867 338-26925 03-1995 48327 4,000
8868 338-26925 03-1995 48328 4,000
8869 338-26925 03-1995 48329 4,400
8870 338-26925 03-1995 48330 4,000
8871 338-26925 03-1995 48331 4,000
8872 338-26925 03-1995 48332 4,000
8873 338-26925 03-1995 48333 4,000
8874 338-26925 03-1995 48334 4,000
8875 338-26925 03-1995 48335 4,400
8876 338-26925 03-1995 48336 4,000
8877 338-26925 03-1995 48337 4,000
8878 338-26925 03-1995 48338 4,000
8879 338-26925 03-1995 48339 4,000 Unit converted from DC to AC traction with new widenose and cab.  Still needs to be painted and put into service.
8880 338-26925 03-1995 48340 4,000
8881 338-26925 03-1995 48341 4,000
8882 338-26925 03-1995 48342 4,000
8883 338-26925 03-1995 48343 4,000
8884 338-26925 03-1995 48344 4,000
8885 338-26925 03-1995 48345 4,000
8886 338-26925 03-1995 48346 4,000
8887 338-26925 03-1995 48347 4,000
8888 338-26925 03-1995 48348 4,000


General Info

NS Model Designation = D9-40C
Horsepower = See roster above
Fuel Tank Capacity = 5,000 gallons
Dynamic Braking = Yes
Control = Single
Cab Signals = No
LSL (Locomotive Speed Limiter) = No

All units are equipped with air conditioning.
